Discover High-Performance HDPE Welding Butt Fusion Machines Macstroc Macfusion series
Compare Our Top HDPE Buttfusion machines from Macstroc
Macfusion160
Compact and Efficient: The Macfusion160 is a versatile butt fusion machine designed for welding HDPE pipes up to 160mm in diameter. Its compact size and powerful performance make it ideal for various applications.
Pipe size range: 40mm - 160mm, suitable for small to medium-sized pipes.
Heating plate maximum temperature: 270°C, with a surface deviation of ±5°C for precision welding.
Adjustable pressure range: 0-7MPa for flexible control during fusion.
Power specifications: 220-230V, 50/60Hz, with a heating plate power of 1kW.
Macfusion250
Increased Capacity: The Macfusion250 offers a larger welding capacity, allowing you to join pipes up to 250mm in diameter. Its robust construction and advanced features ensure precise and efficient welds.
Pipe size range: 63mm - 250mm, designed for a wide range of plastic pipes.
Heating plate maximum temperature: 270°C, ensuring consistent high-quality welds.
Adjustable pressure range: 0-7MPa for versatility in welding applications.
Power specifications: 220-230V, 50/60Hz, with a heating plate power of 2kW for efficient heating.
Macfusion315
Even Larger Pipes: The Macfusion315 is capable of welding HDPE pipes up to 315mm in diameter, making it suitable for a wide range of projects.
Pipe size range: 90mm - 315mm, suitable for larger pipe welding projects.
Heating plate maximum temperature: 270°C, with a surface deviation of ±5°C for precision welding.
Adjustable pressure range: 0-7MPa for flexible control during fusion.
Power specifications: 220-230V, 50/60Hz, with a heating plate power of 3kW.
Macfusion355
Maximum Capacity: The Macfusion355 is the largest machine in the Macstroc Macfusion Series, designed for welding HDPE pipes up to 355mm in diameter.
Pipe size range: 90mm - 355mm, catering to larger-scale pipe installations.
Heating plate maximum temperature: 270°C, ensuring consistent high-quality welds.
Adjustable pressure range: 0-7MPa for versatility in welding applications.
Power specifications: 220-230V, 50/60Hz, with a heating plate power of 4kW for efficient heating.
Macfusion450
The MacFusion450 is ideal for buttfusion welding of pipes ranging from 200 to 450 mm. It heats up to 270°C with a ±7°C variation for precise fusion. With 8.38 kW of power and a pressure range of 0-8 MPa, this 560 kg machine is perfect for medium-scale buttfusion projects in the UAE.
Pipe size range: 200mm - 450mm, designed for larger diameter pipe fusion tasks.
Heating plate maximum temperature: 270°C, with a surface deviation of ±5°C for precision welding.
Adjustable pressure range: 0-7MPa for flexible control during fusion.
Power specifications: 380V [3PH], 50/60Hz, with a heating plate power of 5.38kW for optimal performance.
Macfusion500
The MacFusion500 handles buttfusion welding of pipe sizes from 200 to 500 mm, reaching 270°C with a ±7°C deviation. Operating at 9.5 kW with a 0-8 MPa pressure range, this 700 kg machine is a powerful option for buttfusion in UAE industries.
Pipe Size: 200, 225, 250, 280, 315, 355, 400, 450, 500 mm
Heating plate maximum temperature: 270°C, ensuring consistent high-quality welds.
Adjustable pressure range: 0-8MPa for versatility in welding applications.
Power Specifications: Total power 9.5 kW (Heating Plate 6.5 kW, Planing Tool 1.5 kW, Hydraulic Unit 1.5 kW
Macfusion630
For buttfusion of pipes between 315 and 630 mm, the MacFusion630 delivers a heating plate at 270°C with a 0-8 MPa pressure range. With 13.05 kW of total power, this 780 kg machine is perfect for large-scale buttfusion welding in the UAE.
Pipe Size: 315, 355, 400, 450, 500, 560, 630 mm
Heating plate maximum temperature: 270°C, with a surface deviation of ±5°C for precision welding.
Adjustable pressure range: 0-8MPa for flexible control during fusion.
Power Specifications: Total power 13.05 kW (Heating Plate 9.35 kW, Planing Tool 2.2 kW, Hydraulic Unit 1.5 kW)
Macfusion800
The MacFusion800 supports buttfusion welding for pipes from 450 to 800 mm, with a heating plate reaching 270°C and up to 16 MPa pressure adjustment. Delivering 17.7 kW of power, this 1765 kg machine is ideal for heavy-duty buttfusion applications in the UAE.
Pipe Size: 450, 500, 560, 630, 710, 800 mm
Heating plate maximum temperature: 270°C, ensuring consistent high-quality welds.
Pressure Adjust Range: 0-16 MPa
Power Specifications: Total power 17.7 kW (Heating Plate 12.5 kW, Planing Tool 2.2 kW, Hydraulic Unit 3 kW)
Macfusion1000
Built for buttfusion welding of pipes from 630 to 1000 mm, the MacFusion1000 heats up to 270°C with a pressure range of 0-16 MPa. With 23.5 kW of power and a weight of 2451 kg, this machine is suited for large-scale buttfusion projects in the UAE.
Pipe Size: 630, 710, 800, 900, 1000 mm
Heating plate maximum temperature: 270°C, with a surface deviation of ±5°C for precision welding.
Pressure Adjust Range: 0-16 MPa
Power Specifications: Total power 23.5 kW (Heating Plate 17.5 kW, Planing Tool 3 kW, Hydraulic Unit 3 kW)
Macfusion1200
The MacFusion1200 is designed for buttfusion welding of pipes up to 1200 mm. It operates at 270°C with a pressure range of 0-16 MPa and 28.5 kW of power. Weighing 3685 kg, this machine is built for industrial buttfusion operations in the UAE.
Pipe Size: 630, 710, 800, 1000, 1200 mm
Heating plate maximum temperature: 270°C, ensuring consistent high-quality welds.
Pressure Adjust Range: 0-16 MPa
Power Specifications: Total power 28.5 kW (Heating Plate 21.5 kW, Planing Tool 4 kW, Hydraulic Unit 3 kW)
Explore Our Product Gallery
Explore Our HDPE welding Buttfusion and Electrofusion Diverse Product Range
Macfusion HDPE welding Butt fusion machines
Key Features:
- Robust Basic Frame: Ensures stability and durability.
- Hydraulic Unit: Provides powerful and precise welding.
- Planing Tool: Ensures accurate pipe preparation for optimal welds.
- Heating Plate: Offers precise temperature control for consistent results.
- Basket: Holds the pipe ends securely during the welding process.
- Optional Parts: Expand the machine’s functionality with optional accessories.
- Low Starting Pressure: Suitable for welding small pipes.
- Adjustable Welding Position: Facilitates easy handling of various fittings.
- High-Accuracy Pressure Meter: Ensures precise pressure control.
- Dual-Channel Timer: Records soaking and cooling times for accurate welding.
- Data Logger (Optional): Track and analyze welding parameters for enhanced efficiency.
Applications:
- Water Supply Systems: Welding HDPE pipes for water distribution networks.
- Gas Pipelines: Joining HDPE pipes for gas transportation.
- Industrial Applications: Creating HDPE pipe systems for various industrial processes.
- Infrastructure Projects: Welding HDPE pipes for drainage systems, irrigation systems, and other infrastructure projects.
